Advanced Operation Sorensen DLM-E Series
44 Operation Manual
Figure 4–13.
Using Shutdown with Contact Closure of a Normally OPEN Relay (S1-6 Up)
Figure 4–14.
Using Shutdown with Contact Closure of a Normally OPEN Relay (S1-6 Down)
Figure 4–15.
Using Shutdown with Contact Closure of a Normally CLOSED Relay (S1-6 Up)
