Maintenance and Troubleshooting Sorensen DLM-E Series
54 Operation Manual
5.4
5.5
Ordering Parts
Do not substitute parts without first checking with Sorensen's Service Department. Parts may be
ordered from the factory with the information below. Order parts from:
SORENSEN
Sales & Technical Support
9250 Brown Deer Road
San Diego, CA 92121-2294
1-800-525-2024
Tel: (858) 450-0085
Fax: (858) 458-0267
E-mail: sales@sorensen.com
www.sorensen.com
Note: When ordering parts please include the model number and serial number of the unit with
your order.
Fuse Ratings
Table 5–3 provides a listing of Fuse Ratings.
Reference Designator Fuse Type Rating Size Option
F1, 2, 3 (Rear Panel) Fast Acting, AC F, 25A, 600V 13/32" x 1½ Std
F1, 2, 3 (Rear Panel) Fast Acting, AC F, 10A, 600V 13/32" x 1½ M1
F1, 2, 3 (Rear Panel) Fast Acting, AC F, 8A, 600V 13/32" x 1½ M2
F1 (Inside Chassis) Fast Acting, DC F, 15A, 600V 13/32" x 1½ —
F5, 6 Slow Blow, AC 2A, 250V 5 x 20 mm Leaded —
F7 Fast Acting, DC 0.5A, 125V PCB —
Table 5–3. Fuse Ratings
