Appendix A / Adjustment of short-cycle drawn arc welding guns
Appendix A /14
Item No.
Qty.
Designation
Order No.
42
1
Lift magnet with armature
E03654
43
1
Holding device for magnet
F04036
44
1
Lift adjuster
F04035
45
3
Spring washer M3 DIN127A
***
46
3
Cheese-head screw M3x20 DIN912
***
47
1
Acorn nut M4 DIN6797A
***
48
1
Tooth lock washer M4 DIN6797A
***
49
1
Fillister head screw M4x8 DIN ISO 7380
***
50
3
Spring thrust piece M4x10
***
51
1
Gun label for PH-3N
M03596
52
1
Straight pin 6m6x36 DIN6325
***
53
1
Spring guide for piston
F03879
54
2
Bushing with recirculating ball bearing
F03888
55
1
Pressure spring
F03880
56
1
Working piston
F03887
***
1
Screw kit comprising items:
2/8/9/13/15/17/26/41/45/46/47/48/49/50/52
F04662/FA
