User manual EXPERT 2K-FA
Pag. 18 of 18 Issue 2 – May 2011
All of the automatic features of the linear are retained even in the most complex
configurations, antennas of all kinds can be connected to the connectors "ANT", the
Expert 2K-FA will choose the antennas according to the set-up and will manage them
according to their characteristics.
The CAT is recommended, if the transceiver does not have the CAT or if has only the
"Band Data", the Expert 2K-FA will continue to drive the antenna with the frequency
measured by the counter (data collected after the first transmission) .
Up to 6 tuneable antennas can be controlled through their own controller.
The simplest configuration is a single tuneable antenna according to the following
diagram :
The link is unique for any position (ANT 1,2,3,4,5,6) you want use.
