Page 16 MZC-66 Hardware Installation Instructions

8. ACQUIRE ALL SYSTEM COMPONENTS — Set up the system, and program and test all functions before tak-

ing the electronics to the job site. This can save valuable time in assuring that all system components work and the

system is functioning as designed. Connecting and testing the system prior to installation will also help assure that all

parts and pieces that will go into the system are in hand, so time is spent on the job site and not running around town

shopping for parts or not being able to ﬁ nish the installation while waiting for an air shipment of a ten dollar part.

9. HEAD-END CONSIDERATIONS — The system head-end should be in a convenient, central location that provides

easy access for the user, to be able to load discs, video tapes etc. The location should also be accessible for service and

ideally would have either have rear access to the system connections or a pull-out rack that allows access to system

connections. All system wire runs should terminate at the head-end. There should be sufﬁ cient mounting space for all

system components and the wires and cables that connect them. Leave plenty of room for airﬂ ow for proper ventilation

or system components could be damaged. Too tight of a space that does not leave room for system wiring or a poorly

dressed system can cause thermal problems. Wires jumbled in around system components can act as an insulator or

block free airﬂ ow which can damage the components from overheating. Incorporate a proper ventilation system using

cooling fans (SpeakerCraft ESC-1) for systems with external ampliﬁ ers or other components that generate excess heat.

When possible, leave extra space for future expansion of the system for additional zone and source components.

10. ZONE CONSIDERATIONS — Identify all room components and their locations. Typically, a keypad would be mounted

near the entry to a room. If the room orientation of where the TV/Video Display and speakers are located leaves the

keypad behind the user, an additional IR receiver on the same wall as the TV and speakers will help make controlling the

system more user friendly. Be sure to include an appropriate wire run for the IR receiver. Additional wire runs for control-

ling lifts, screens and drapes should also be considered. Try to avoid mounting keypads and IR receivers in locations that

will be exposed to direct sunlight. Leave extra wire at keypad and in-wall speaker locations so these components can be

easily removed without pulling on wires and possibly have them fall down inside the wall, should service be necessary.
