Page 20 MZC-66 Hardware Installation Instructions

SOURCE IR OUT

Requirement - Use SpeakerCraft standard IR emitters (IRE-1.0, 2.0, 3.0, 4.0).

Installation - Attach emitter to Source Component. Connect emitter mini-plug to the appropriate Source IR OUT.

SOURCE IR LOOP

Requirement - Use pre-made 3.5mm mini to mini plug cables.

Installation - Connect Source IR OUT on one MZC-66 to the same source number Source IR LOOP on the next MZC-

66 when using multiple MZC-66s in expanded systems. i.e. MZC Slave 2 Source 1 IR OUT to MZC Slave 1 Source

1 LOOP; MZC Slave 1 Source 1 IR OUT to MZC Master Source 1 LOOP; MZC Master Source 1 IR OUT to an

emitter for Source 1 IR control. See section: Expanded Systems for additional information.

SOURCE AUDIO/VIDEO INPUT

Requirement - Use quality, RCA to RCA Audio/Video cables with gold ends.

Installation - Connect one end to Source L & R line-level audio OUT and COMPOSITE video OUT, and connect

the other end to the appropriate Source L & R line-level audio and composite video INPUT on the MZC-66 Rear

Panel.

SOURCE AUDIO/VIDEO LOOP

Requirement - Use quality, RCA to RCA Audio/Video cables with gold ends.

Installation - Connect Source L & R line-level audio and composite video LOOP on one MZC-66 to the SAME

SOURCE NUMBER Source L & R line-level audio and composite video INPUT on the next MZC-66 when using

multiple MZC-66s in expanded systems. i.e. MZC-66 MASTER Source 1 L & R line-level audio and composite video

LOOP to MZC-66 SLAVE 1, Source 1, L & R line-level audio and composite video INPUT; MZC SLAVE 1, Source

1, L & R line-level audio and composite video LOOP to MZC-66 SLAVE 2, Source 1, L & R line-level audio and

composite video INPUT. See Section: Expanded Systems.

ZONE PRE-OUT

Requirement - Use quality, RCA to RCA stereo audio cables with gold ends.

Installation - Connect one end to Zone L & R line-level audio PRE-OUT and connect the other end to the

appropriate L & R line-level audio INPUTS on an external ampliﬁ er. (Set VC/NVC Switch for Volume Control/No

Volume Control as appropriate.) See Section: External Ampliﬁ ers for additional information.

ZONE IR OUT

Requirement - Use SpeakerCraft standard IR emitters (IRE-1.0, 2.0, 3.0, 4.0).

Installation - Attach emitter to Zone Source Component. Connect emitter mini plug to the appropriate Zone IR

OUT.
