42 SPECTROMAXx —
5. In order to remove the electrode
(1), unscrew the spacer (2).
Behind the plug there is a
through hole in order to reach
the fixing screw of the electrode.
Fig. 21
6. Loosen the fixing screw of the
electrode (1), using the Allen
key (AF 2) until the electrode
can be removed.
When loosening the
electrode, hold firmly on to
it. After loosening the
screw, a spring presses the
screw upward. Loosen the
screw only until the
electrode can be removed
easily.
7. Remove and clean the
electrode.
If the electrode is worn, it
must be replaced.
8. Remove the spark stand insert
(1). Use a dry, grease-free cloth
to clean the insert.
Fig. 23
