SPEKTRUM DX10t • RADIO INSTRUCTION MANUAL
EN
6-4 Wing Type
Use the Wing Type function to select the wing and tail
that match your airplane.
Wing Types:
2 x Aileron, 2 x Flaps
• Elevon
• Elevon B
• 1x Aileron, 2 Flaps
• 1 x Aileron, 1 Flap
• Flaperon
• 2 x Aileron
• 1 x Aileron
• Tail Types
• Normal
• V Tail (A)
• V Tail (B)
• 2 x Elevator
• 2 x Rudder
• 2x Rudder, 2 x Elevator
The selected wing and tail Types are in correlation with
the Function List.
6-3 Model Name
The Model Name function allows you to name a model.
That makes identifying and selecting much easier as this
name is shown on the display.
6-5 Flight Mode
The F-Mode Setup is used to assign the switches that
will be used for Flight Mode. The actual F-Mode is on the
display.
6-8 Trim Setup
The Trim Step function allows servo movement
adjustment per click of trim.
For maximum trim, use 8–10 clicks, 5 clicks for middle
trim, the minimum trim is 1 click. If 0 is selected, the trim
function is inhibited.
6-6 Name Flight Mode
With the F-Mode Name, you can assign and edit Names
for the Flight Modes. There are four F-Mode Names
you can edit: Launch, Cruise, Land and Autorotation
(Helicopter only).
6-7 Channel Assign
The Channel Assign function is used to assign or change
channels.
In the Window below you see the Note on X-Plus
The X-Plus Module offers all Spektrum 10-channel radios
and receivers 8 proportional channels. The X-Plus
activation will be done in this menu.
