6 Technical Specifications
6.1 Technical properties
Compressor
Hermetic with the automatic recovey of oil
Power
250 watt –
Recovery capacity (liquid fase)
300g/min –
Vacuum pump
Single-stage
Capacity
100lt/min
Vacuum level
7x10
2
Vacuum test
Automatic, with audible alarm and display message
Storage bottle
two containers and security valve
Refrigerant capacity
R134a 10,0 Kg – HFO1234yf 10,0 Kg
Low and high pressure gauges
Analogical – Ø80 - cl 1
Precision scale
± 5g
Power supply
230 V / 50 Hz
Loudness
Under 70dB (measured with sound level meter class 2 according to
standards IEC 651 and IEC 804)
Hose length
3 mt each
Machine dimensions
590 x 610 x h 1120 mm
Weight
85Kg
24 columns printer
6.2 Keyboard
“Right / Left arrow” buttons to move along the menù
“UP / Down arrow” buttons to modify the parameters
“Enter” button to confirm
“C” button to exit the functions
“DataBase” button to enter into the Data Base
“Print” button to print the last operation performed
“F” multifunction button
6.3 Included accessories
• nr. 1 plastic dispenser of 250 g to inject standard fresh oil
• nr. 1 plastic dispenser of 250 g to drain the used oil
• nr. 1 plastic dispenser of 250 g to inject hybrid fresh oil
• nr. 1 power supply cable
• nr. 1 low pressure quick coupling for R134a
• nr. 1 high pressure quick coupling for R134a
• nr. 1 low pressure quick coupling for HFO1234yf
• nr. 1 high pressure quick coupling for HFO1234yf
• nro. 2 hoses (1 for high pressure and 1 for low pressure) 3mt
long
Image 3 – Included Accessories
Image 2 – Keypad
