8 Description of the station
Referred to the following pictures.
REFERENCES
Img. 6 A
Low pressure gauge
Img. 6 B
Graphic display with data view/pressures/settings/gas amount inside the bottle
Img. 6 C
High pressure gauge
Img. 6 D
Internal R134 bottle pressure gauge
Img. 6 E
9 key Keyboard
Img. 6 F
Internal HFO1234yf bottle pressure gauge
Img. 7 A
Connection fittings for external high pressure (Hp) and low pressure (Lp) hoses
Img. 7 B
High pressure (Hp) and Low pressure (Lp) taps
Img. 7 C
Housing for R134 quick couplings
Img. 7 D
Housing for HFO1234yf quick couplings
Img. 7 E
Main switch with protection fuses
Image 5 - Station
