06/02/2020 Vers. 0.0 57
Use the arrow “right/left” keys to search the desired brand and confirm the option by pressing the “Enter” key.
Select the desired vehicle by pressing the “Enter” key.
Use the arrow “right/left” keys to search the version of the selected model. It can be seen on the display the vehicle
model, the type of gas used and the amount of current gas in the system.
Select the system type standard/ hybriddesired and confirm the procedure by pressing “Enter”.
Take Notice: if it is selected a different system type from the previous one programmed, it will start an Internal
Cleaning.
WARNING!: Before selecting the system type ensure that the two quick fittings of high and low pressure located at
the end of the hoses are connected to the two male connectors on the station (img 6-g)
DO NOT EVER RUN AN INTERNAL CLEANING WITH THE FITTINGS CONNECTED TO THE VEHICLE
WAIT until the end of the internal cleaning to proceed. The cleaning operation will end when the display shows a
message, after the oil drain.
WARNING! If the internal cleaning is interrupted it will be requie every time, even selecting the same system type.
Select “Start” to run automatically the whole cycle.
The standars can be modify “temporarily” and it’s possible to perform the various functions separately (Recovery
(R), Vacuum (V), Vacuum Test (T), Oil Injection (standard/hybrid), Gas Charge (C)) following the instructions
contained in section "Manual/Automatic".
10.5.1 Personal DataBase
Parameters Storing
The personal database can contain up to 100 positions.
To store the data you have to enter in the menue DataBase and choose the category PersonalDB.
Select the position on where you want to store the data.
It will appear the following screen:
Set the parameters of the functions Vacuum (minutes), Vacuum Test (minutes), Oil Charge (grams), Gas Charge
(grams).
Press “C” button to store the data set.
Use of the stored data
At first select the desired refrigerant (R134 or HFO1234YF) from the page Home.
