Spinlab Bird Dog Plus 5000 - Form 14 Meters: 4 Wire Wye; Form 15 & 17 Meter: 4 Wire Delta

104
6000 Bird Dog Plus Only
F.3.2.10 Form 14 Meters: 4 Wire Wye—The Form 14 meter has 3 current
coils and 2 ½ stators. It is a 3 phase self-contained meter. It will require 1 test to
determine the accuracy of the meter. The hookup is as follows:
Automatic Phase Rotation Test—Voltage Cable Hookup
Red alligator clip—Phase A
White alligator clip—Neutral
Black alligator clip—Phase C
Yellow (or green for older units) alligator clip leave unconnected
Meter Test Hookup
Secondary Voltage Cable
o Red alligator clip to phase A
o White alligator clip to neutral.
o Black alligator clip to phase C
o Yellow (or green for older units) alligator clip leave unconnected
Clamp-on CTs
o A phase clamp-on connected to phase A (I
A
) wire
o B phase clamp-on connected to phase B (I
B
) wire
o C phase clamp-on connected to phase C (I
C
) wire
Form 14 4 Wire Wye with ABC Rotation Form 14 4 Wire Wye with CBA Rotation
Unity Power Factor Unity Power Factor
F.3.2.11 Form 15 & 17 Meter: 4 Wire Delta—The Form 15 & 17 meter
has 3 current coils and 2 stators. It is a 3 phase self-contained meter. It will require
1 test to determine the accuracy of the meter. The hookup is as follows:
Automatic Phase Rotation Test—Voltage Cable Hookup
Red alligator clip—Phase A
Yellow (or green for older units) alligator clip—Phase B
Black alligator clip—Phase C
White alligator clip—Neutral
