Spinlab Bird Dog Plus 5000 - Form 16 Meter: 4 Wire Wye

105
6000 Bird Dog Plus Only
Meter Test Hookup
Secondary Voltage Cable
o Red alligator clip to phase A
o Yellow (or green for older units) alligator clip to phase B
o Black alligator clip to phase C
o White alligator clip to neutral
Clamp-on CTs
o A phase clamp-on connected to phase A (I
A
) wire
o B phase clamp-on connected to phase B (I
B
) wire
o C phase clamp-on connected to phase C (I
C
) wire
Form 15 & 17 4 Wire Delta ABC Rotation Form 15 & 17 4 Wire Delta CBA Rotation
Unity Power Factor Unity Power Factor
F.3.2.12 Form 16: 4 Wire Wye—The Form 16 meter has 3 current coils and
3 stators. It is a 3 phase self-contained meter. It will require 1 test to determine the
accuracy of the meter. The hookup is as follows:
Automatic Phase Rotation Test—Voltage Cable Hookup
Red alligator clip—Phase A
Yellow (or green for older units) alligator clip—Phase B
Black alligator clip—Phase C
White alligator clip—Neutral
Meter Test Hookup
Secondary Voltage Cable
o Red alligator clip to phase A
o Yellow (or green for older units) alligator clip to phase B
o Black alligator clip to phase C
o White alligator clip to neutral
