6000 Bird Dog Plus Only
Clamp-on CTs
o A phase clamp-on connected to phase A (I
A
) wire
o B phase clamp-on connected to phase B (I
B
) wire
o C phase clamp-on connected to phase C (I
C
) wire
Form 16 4 Wire Wye with ABC Rotation Form 16 4 Wire Wye with CBA Rotation
Unity Power Factor Unity Power Factor
