17
AL1 DEL S
0
AL2 LOW%
20
AL2 HYST%
5
AL2 DEL S
0
OFFSET%
0
The display will always revert to displaying the current level percentage if a button has not
been pressed for 5 minutes.
Shows the delay in seconds (damping effect for turbulent
conditions), chosen for ALARM 1.
Alarm 2 is set to a LOW or HIGH water alarm. Its value is a
percentage of the gauge glass.
Shows the hysteresis selected for alarm 2. Its value is a
percentage of the gauge glass.
Shows the delay in seconds (damping effect for turbulent
conditions), chosen for ALARM 2.
Only shows if steam meter selected, (two element control). Shows
% offset of steam meter. Its value is a percentage of the gauge
glass.
