SP500 Electropneumatic Smart Positioner
9.1 Set-up now
•
Programming notes
The positioner fitted to this control valve requires programming. A minimum input signal of 3.6 mA is required
to power the positioner. To program the positioner it is necessary to enter SP500 MENU and carry out an
autostroke commissioning routine (AUTOS) prior to putting the control valve into automatic operation.
A flow chart is included in Section 8 to guide you through the procedure. The display provides a flag indication
of the active main menu function.
To enter SP500 MENU press and hold key for 3 seconds. The display will count down the 3 seconds.
Commissioning notes
Main menu functions include:
SP500 MENU
View software version, mounting position check, reset default values.
MANOP
Manual control of valve movement (Actuator inflation/deflation).
AUTOS
Automatic valve commissioning. Provides selection of % travel display.
SET
Setting of valve type, control action, travel limits and input signal span.
TUNE
Setting of deadband, tight shut-off, lift characterisation, travel time and software
switches.
RUN
Activates automatic operation plus input signal, total valve strokes and total
run time. Also provides route for returning to SP500 MENU.
Note: SET, TUNE and RUN functions are restricted and can only be accessed on completion of a
successful autostroke routine (AUTOS).
9. Programming and commissioning
