SP500 Electropneumatic Smart Positioner
12.1 Main menu display functions
Display Description
SET UP
NOW
Indicates that the SP500 positioner fitted to the valve has not been programmed or
commissioned.
SP500
MENU
Indicates that you have now entered the SP500 main menu.
Provides access to:
•
View the version of the embedded software.
•
Facility to centre the mounting position (CALIB).
•
Retain temporary changes to menu values (RETRN).
•
Recall previously stored menu values (RTAIN).
•
Reset to default values (RESET).
MAN OP
Provides access to manual control (MCTL) and current calibration (C-CAL).
AUTOS
Provides access to:
•
Autostroke commissioning routine.
Note: SET, TUNE and RUN functions can only be accessed after
a successful AUTOSTROKE routine has been completed.
•
Selection of percentage travel display % (TR AVL).
SET
Provides access to valve set up functions as follows:
•
Valve type (VALVE).
•
Actuator type (ACT).
•
Control action (CTRLA).
•
Minimum valve travel (MIN-T).
•
Maximum valve travel (MAX-T).
•
Displayed % travel (DTRVL).
•
Minimum signal range (MIN-R).
•
Maximum signal range (MAX-R).
12. Glossary of display data
