SP7-20 Smart Positioner
5.2.1 SP7-20 Parameter description HART
Parameter Display Function
Possible
parameter
setting
Unit
Factory
setting
P1._ STANDARD
P1.0 ACTUATOR Actuator type Actuator type LINEAR, ROTARY --- LINEAR
P1.1 AUTO_ADJ
Automatic
adjustment
Autoadjust Function --- ---
P1.2 ADJ_MODE
Auto adjust
mode
Automatic
adjustment
mode
FULL,
STROKE,CTRL_PAR,
ZERO_POS,
LOCKED
FULL
P1.3 TEST Test Test Function --- INACTIVE
P1.4 FIND_DEV Find device Find device
DISABLE, ONE TIME,
CONTINOUS
--- DISABLE
P1.5 EXIT Return
Return to
operating level
Function --- NV_SAVE
P2._ SETPOINT
P2.0 MIN_RGE
Min setpoint
range
Min. setpoint
range
4.0 to 18.4 mA 4.0
P2 .1 MAX_RGE
Max setpoint
range
Max. setpoint
range
20.0 to 5.6 mA 20.0
P2.2 CHARACT
Charact.
curve
Characteristic
curve
LINEAR, 1:25, 1:50,
25:1, 50:1, USERD
--- LINEAR
P2.3 ACTION Valve action
Direction of
action
DIRECT, REVERSE --- DIRECT
P2.4 SHUT_CLS
Shut-off value
0%
Shut-off value
0 %
OFF, 0.1 to 45.0 % 1.0
P2.5 SHUT_OPN
Shut off value
100%
Shut-off value
100%
55.0 to 100.0, OFF % OFF
P2.6 RAMP UP
Set point
ramp, up
Setpoint ramp
(up)
OFF, 0 to 200 --- OFF
P2.7 RAMP DN
Set point
ramp, down
Setpoint ramp
(down)
OFF, 0 to 200 --- OFF
P2.8 EXIT Return
Return to
operating level
Function --- NV_SAVE
P3._ ACTUATOR
P3.0 MIN_RGE
Min. of stroke
range
Operating
range, min.
0.0 to 90.0 % 0.0
P3.1 MAX_RGE
Max. of stroke
range
Operating
range, max.
100.0 to 10.0 % 100
P3.2 ZERO_POS Zero position Zero position
CLOCKWISE,
CTCLOCKWISE
--- CTCLOCKWISE
P3.3 EXIT Return
Return to
operating level
Function --- NV_SAVE
