SP7-20 Smart Positioner
Parameter Display Function
Possible
parameter
setting
Unit
Factory
setting
P4._ MESSAGES
P4.0 TIME_OUT
Control time
out
Dead band time
limit
OFF, to 200 --- OFF
P4.1 POS_SW1
Position
switch 1
Switching point
SW1
0.0 to 100.0 % 0.0
P4.2 POS_SW2
Position
switch 2
Switching point
SW2
0.0 to 100.0 % 100.0
P4.3 SW1_ACTV
Switchpoint 1
enable
Active direction
SW1
FALL_BEL, EXCEED --- FALL_BEL
P4.4 SW2_ACTV
Switchpoint 2
enable
Active direction
SW2
FALL_BEL, EXCEED --- EXCEED
P4.5 EXIT Return
Return to
operating level
Function --- NV_SAVE
P5._ ALARMS
P5.0 LEAKAGE
Leakage
detection
Leakage to
actuator
ACTIVE, INACTIVE --- INACTIVE
P5.1 SP_ RGE
Setpoint rng
monitor
Outside the
setpoint range
ACTIVE, INACTIVE --- INACTIVE
P5.2 SENS_RGE
Sens. range
monitor
Operating range
exceeded
ACTIVE, INACTIVE --- INACTIVE
P5.3 CTRLER
Controller
monitor
Controller
inactive
ACTIVE, INACTIVE --- INACTIVE
P5.4 TIME_OUT
Control time
out
Dead band time
limit
ACTIVE, INACTIVE --- INACTIVE
P5.5 STRK_CTR
Stroke
counter
Movement
counter
ACTIVE, INACTIVE --- INACTIVE
P5.6 TRAVEL Travel counter Travel counter ACTIVE, INACTIVE --- INACTIVE
P5.7 EXIT Return
Return to
operating level
Function --- NV_SAVE
P6._ MAN_ADJ
P6.0 MIN_VR
Min. valve
range
Operating
range, min.
0.0 to 100.0 % 0
P6.1 MAX_VR
Max. valve
range
Operating
range, max.
0.0 to 100.0 % 100
P6.2 ACTUATOR Actuator type Actuator type LINEAR, ROTARY --- LINEAR
P6.3 SPRNG_Y2
Spring action
(Y2)
Spring action
(Y2)
CLOCKWISE,
CTCLOCKWISE
--- CTCLOCKWISE
P6.4 DANG_DN
Dead angle
close
Dead angle 0 % 0.0 to 45.0 % 0.0
P6.5 DANG_UP
Dead angle
open
Dead angle
100%
55.0 to 100.0 % 100.0
P6.6 BOLT_POS Bolt position
Actuator
position
LEVER, STEM --- LEVER
P6.7 EXIT Return
Return to
operating level
Function --- NV_SAVE
5.2.1 SP7-20 Parameter description HART (continued)
