Spirax Sarco SP7-20 - SP7-20 HART Parameters (Part 4); Digital Output, Input, and IP Module Parameters

IM-P706-03 CTLS Issue 1
43
SP7-20 Smart Positioner
Parameter Display Function
Possible
parameter
setting
Unit
Factory
setting
P9._ DIG_OUT
P9.0 ALRM_LOG Alarm logic
Alarm output
logic
ACTIVE_HI,
ACTIVE_LO
--- ACTIVE_HI
P9.1 SW1_LOG
Switchpoint 1
logic
Logic SW1
ACTIVE_HI,
ACTIVE_LO
--- ACTIVE_HI
P9.2 SW2_LOG
Switchpoint 2
logic
Logic SW2
ACTIVE_HI,
ACTIVE_LO
--- ACTIVE_HI
P9.3 TEST Test Test Function --- NONE
P9.4 EXIT Return
Return to
operating level
Function --- NV_SAVE
P10._ DIG_IN
P10.0 FUNCTION
Function
select
Function
selection
NONE, POS_0 %,
POS_100 %, POS_
HOLD
--- NONE
P10.1 EXIT Return
Return to
operating level
Function --- ---
P11._ FS/IP
P11.0 FAIL_POS Save position Safe position ACTIVE, INACTIVE --- INACTIVE
P11.1 FACT_SET
Factory
setting
Factory setting Function --- START
P11.2 IP-TYP
I/P module
type
Type of l/P
module
NO_ F_POS,F_
SAFE_1,F_SAFE_2,
S 30
P11.3* IP_CO M P
IP
compensation
IP
compensation
ON, OFF --- ON
P11.4 HART_REV HART revision HART revision 5; 7 --- 5
P11.5 EXIT Return
Return to
operating level
Function --- NV_SAVE
*Activation by Spirax Sarco Service only
Note
For detailed information on the parameterization of the device, consult the associated configuration and
parameterization instructions.
5.2.1 SP7-20 Parameter description HART (continued)
