ECU must be programmed with Ver. 2.1 PC software. Older version software than Ver.1.13 will
open and change parameters but will not be able to save the data. From Ver.1.14 software will
also warn if incompatible ECU firmware is used. The alphabetic number will indicate later version
changes in the ECU or PC but does not change the protocol of Ver.2.1 software. This may differ
from software to ECU but does not matter.
Program is a number given to each ECU firmware program to identify them apart. Behind the
number is a short explanation of the type of program On the CD a list of these numbers available
(Program Numbers.txt).
Serial Number is keep track of each ECU sold. It is also engraved on the enclosure of the ECU.
The number for ex PP-PP-999999-15 means as follows:
PP – Agent which this unit was distributed to
PP – Customer which this unit was sold to – this can be changed by the Agent for his own
reference.
999999 – serial number
15 – model function no
ECU model function numbers are as follows:
3 Standard ECU
11 Intermediate ECU
15 Advance ECU
6.7 Setup (F2)
6.7.1 Engine Setup (Alt 1)
6.7.2 Timing Setup (Alt 2)
6.7.3 Fuel Setup (Alt 3)
6.7.4 Sensor Setup (Alt 4)
6.7.5 Turbo Setup (Alt 4)
6.7.6 Real-Time Data and Bars
