12
Mayhem 130 Frame Component Compability
Your Mayhem frame was designed to work with the following components. Other components may be
compable, but tment is not guaranteed. For quesons regarding component compability of parts
not listed below please contact Spot.
COMPONENT FIT, STANDARD
HEADSET UPPER: ZS44, LOWER: ZS56
BOTTOM BRACKET BSA THREADED, 73mm SHELL WIDTH
SEATPOST 31.6, INTERNAL DROPPER ROUTING
CHAINRING >51mm CHAINLINE, 30-34t RING
REAR HUB 12 X 148, SRAM UDH MAXLE INCLUDED
REAR BRAKE 160mm STANDARD POST MOUNT, 180mm MAX ROTOR DIAMETER
REAR TIRE 29 X 2.5" / 64mm MAX WIDTH. ACTUAL TIRE WIDTHS CAN VARY FROM PRINTED SIZES
REAR SHOCK 230 X 57.5, FRONT EYELET Ø8 X 25mm, REAR EYELET OPEN, NO BUSHINGS
FORK TRAVEL 140-150mm
WATER BOTTLE 2X BOTTLE MOUNTS, ONE ABOVE AND ONE BELOW DOWNTUBE
SEATPOST COLLAR 35.0mm INNER DIAMETER
CHAINGUIDE ISCG-05 MOUNTS, UPPER GUIDE MUST BE MINIMAL SIZE
