Mayhem 130/150 Frame Parts Reference
ITEM NO. PART NUMBER DESCRIPTION QTY.
1 FS90102 PIVOT AXLE CONE, DS LOWER 1
2 FS90093 PIVOT AXLE CONE, NDS 2
3 FS80012 WASHER, M6 HIGH COLLAR 2
4 FS90147 M6 X 38 TORX CAP SCREW 1
5 FS80005 BEARING, ENDURO 3802 LLU MAX 6
6 FS90091 PIVOT CAP, 15mm 4
7 FS90090 PIVOT AXLE CONE, DS UPPER 1
8 FS90089 M6 X 24 TORX CAP SCREW 1
9 FS90088 WASHER, 15mm 4
10 FS90168 2020 MAYHEM PIVOT YOKE 1
11 FS90174 2020 MAYHEM UPPER LINK 1
12 FS80002 BEARING, ENDURO 1017 2RS MAX 2
13 FS90170 2020 MAYHEM YOKE WASHER 2
14 FS90148 2020 MAYHEM YOKE PIVOT AXLE 2
15 FS90149 2020 MAYHEM UPPER LINK PIVOT AXLE 2
16 FS90172 2020 MAYHEM 130 SHOCK YOKE 1
17 FS90166 2020 MAYHEM SHOCK PIN, R 1
18 FS90048 SHOCK PIVOT NUT 1
19 FS90171 2020 MAYHEM OFFSET REDUCER 1
20 FS90167 SHOCK REDUCER SPACER 1
21 FS90165 2020 MAYHEM 130 SHOCK PIN, F 1
22 FS80003 M6 X 11 TORX 1
23 FS80006 M5 X 13 TORX 7
24 FS80007 P-CLIP 3
25 FS90083 BRAKE MOUNT 1
26 FS90161 LEAF SPRING SCREW 32 4
27 FS90112 LEAF SPRING SPOOLER, MAYHEM 1
28 FS90160 LEAF SPRING SCREW 21.0 4
29 FS90158 2020 MAYHEM LEAF SPRING CAP, F 1
30 FS90159 2020 MAYHEM LEAF SPRING CAP, R 1
31 FS90150 2020 MAYHEM UPPER PIVOT CAP 2
32 FS90157 2020 MAYHEM SCREW COVER, F 1
33 FS90156 2020 MAYHEM SCREW COVER R 1
34 FS80017 O-RING 1.5 X 18 12
35 FS80010 O-RING 1.5 X 12 4
36 FS90155 2020 MAYHEM COMPRESSION PLATE 1
37 FS90154 2020 MAYHEM DT PROTECTOR 1
38 FS90153 2020 MAYHEM STRUT PROTECTOR 1
39 FS90179 2020 MAYHEM 130 FRONT TRIANGLE, L 1
40 FS90176 2020 MAYHEM REAR TRIANGLE 1
41 SRAM 00.7918.089.000 SRAM UDH RD HANGER 1
42 INC W/ RD HANGER SRAM UDH HANGER SCREW 1
43 FS90025 PIVOT WASHER, MAIN 2
44 FS90172 2020 MAYHEM COMPRESSION CAP 1
45 FS90059 LEAF SPRING WASHER V2 4
46 FS90151 2020 MAYHEM LEAF SPRING 1
48 SS PROTECTOR 1
49 CHAINSTAY PROTECTOR 1
