APV

Ws+Sectional Drawing

1: Pump housing

2: Air screw

3: O-ring

4: Impeller

6: O-ring

7: Back plate

8: Locating pin

9: Clamp ring

11: Shaft

12: Screw

13: Shaft guard

14: Extension frame

15: Bracket (screw)

16: Screw

17: Spacer flange

25: Clamp ring

26: O-ring

27: Front cover

28: Clamp ring

29: Gasket

30: Recirculationpipe

Section 1: Single seal for shaft size ø25 and ø35

Section 2: Double seal with liquid flushing for shaft size ø25 and ø35

5.1: Seal housing

5.3: Pressure ring

5.4: Drain pipe

5.5: O-rings

5.6: Stationary seal face

5.7: Rotary seal face

5.8: Pin

5.9: Seal housing

5.10: O-ring

5.11: Pressure ring
