APV
381497 USA 10/2014
7. Ws+ Spare Parts, Dimensions
23
7.2 Pump Parts
Pump Type
Ws+20/15 Ws+30/30 Ws+44/50
Pos Qty Description Part No.
1a 1 Pump casing L804669 L804670 L804671
1b 1 Pump casing L182857 L182858 L182859
2 1 Air screw L804675 L804676 L804677
3 1 O-ring see page 27
4 1 Impeller see page 24
5 1 Shaft seal see page 25/26
6 1 O-ring see page 27
7 1 Back Flange L260948* L260950 L260954
8 1 Pin ------ L772493 L772493
9 1 Clamp ring L188430 L188436 L188432
11 1 Shaft see page 28
12 2 Screw see page 28
13 2 Shaft guard see page 29
14 1 Extension frame see page 29
15 2 Bracket ------ L268499 L268499
16 2 Screw ------ L701942 L701942
17 1 Flange Adapter see page 29
18 1 Motor See order
25 1 Clamp ring L169050 L188430 L804665
26 1 O-ring see page 27
27a 1 Front cover L804672 L804673 L804674
27b 1 Front cover L808296 L808297 L808298
28 2 Clamp ring L771837 L771837 L771837
29 2 Gasket see page 27
30 1 Recirculation pipe L808288 L808289 L808290
31 1 Spacer/Plastic star L259776 L259776 L260406
-- -- Frame see page 30
* integrated in extension frame, pos. 14
