SPX APV Ws+20/15 User Manual

i
381497 USA 10-2014
APV
Contents: USA
Section Page Description
- 1 Introduction
- 3 Warnings
- 6 Important Warnings
- 8 Sectional Drawing
1 10 Introduction to the Ws+
1.1 - Ws+ range
1.2 - Selection of the standard or simplified pump
1.3 - The Ws+ pump, options and extras
1.4 - Identifying the pump model
2 11 Installation of the pump
2.1 - Reminder
2.2 - Installation of pump
2.3 12 Installation of pump without recirculation
2.4 - Lining up the pipe system
2.5 - Power supply
2.6 - Water supply for water-flushed shaft seal
3 13 Before start-up
3.1 - Checking the pump body for foreign material
3.2 - Testing the pump
4 14 Putting the pump into service
4.1 - Flushing water
5 14 Maintenance
5.1 - Checking the shaft seal
5.2 - Replacing the shaft seal
5.3 16 Replacement of motor
5.4 17 Recommended spare parts
6 18 Technical data
6.1 - Maximum permissible outlet pressure
6.2 Required torques
7 20 Ws+ Spare Parts, Dimensions
7.1 - Pump Dimensions
7.2 22 Pump Parts
7.3 24 Impeller
7.4 25 Shaft Seal
7.5 27 Seal Kit
7.6 28 Shaft
7.7 29 Extension Frame and Shaft Guard
7.8 30 Frame

SPX APV Ws+20/15 Specifications

General

Brand	SPX
Model	APV Ws+20/15
Category	Water Pump
Language	English
