St George DEO2A - UES-2 A Installation Dimensions & Load

44
CABINET INSTALLATION INSTRUCTIONS
NOTE: The dimensions shown here are integrated flush-
mounted as recommended by St. George.
For dimensions of other installation types see chart
below.
ELECTRICAL LOADS
The maximum electrical loading for the appliance is 4.3kW.
800
573
580
100
VOID
80
760
500
570
797
575
20
UES-2A
HEIGHT WIDTH DEPTH
FLUSH 573 800 580
TRIM EXPOSED 565 764 560
