Hardware layout UM1670
10/32 UM1670 Rev 4
6 Hardware layout
The STM32F429 Discovery board has been designed around the STM32F429ZIT6
microcontroller in a 144-pin LQFP package.
Figure 2 illustrates the connections between the STM32F429ZIT6 and its peripherals
(ST-LINK/V2-B, push-buttons, LEDs, USB OTG, ST-MEMS gyroscope, accelerometer,
magnetometer, and connectors).
Figure 3 and Figure 4 show the location of these features on the STM32F429 Discovery
board.
Figure 5 shows the mechanical dimensions of the STM32F429 Discovery board.
Figure 2. Hardware block diagram
MSv32376V3
Embedded
ST-LINK/V2-B
STM32F429ZIT6
I/O
I/O
I/O
RESET
LEDs
LD3...LD6
SDRAM
64 Mbits
B2
RESET
B1
USER
I3G4250D
Micro USB
Mini USB
SWD
Header
Header
2.4" QVGA
TFT LCD
I
2
C ext
