UM1670 Rev 4 11/32
UM1670 Hardware layout
31
6.1 STM32F429 Discovery board layout
Figure 3. Top layout
LD1
COM (red/green LED)
ST-LINK/V2-B
CN2
SWD connector
B1
user button
JP3
I
DD
measurement
LD3
(orange LED)
LD4
(green LED)
2.4" TFT LCD
B2
reset button
3 V power supply input/output
SB1
(B2 – RESET)
CN4
ST-LINK/DISCOVERY selector
LD2
PWR (red LED)
