Figure 6 and Figure 7 provide the mechanical dimensions of the STM32H7B3I-DK board.

Figure 6. STM32H7B3I-DK board mechanical dimensions (top view, in millimeters)

75.00

161.00

Figure 7. STM32H7B3I-DK board mechanical dimensions (bottom view, in millimeters)

55.33

5.00

5.00 5.00

5.00

17.40

7.20

22.22

7.20

22.22

UM2569

Hardware layout and configuration

UM2569 - Rev 6

page 10/53
