Pin number GPIO port Signal or label Comment

M13 PB13 ULPI_D6 -

M14 PB14

PMOD9-MISOs

ARD_D12

SPI2_MISO

M15 PB15

PMOD8-MOSIs

ARD_D11

SPI2_MOSI

TIM1_CH3N

L3 PC0 ULPI_STP -

M2 PC1 OCSPI1_IO4 -

J5 PC2 PMOD3-MISOp SPI2_MISO

N3 PC3 PMOD2-MOSIp SPI2_MOSI

M6 PC4 ARD_A1 ADC12_INP4

N6 PC5 OCSPI1_DQS -

F14 PC6 PMOD11-INT -

E15 PC7 PMOD17-DF-D3 DFSDM1_DATIN3

F13 PC8 SDIO1_D0 -

E14 PC9

SDIO1_D1

DCMI_D3

A13 PC10 SDIO1_D2 -

D11 PC11

SDIO1_D3

DCMI_D4

B12 PC12 SDIO1_CK -

F4 PC13 WAKEUP -

D1 PC14-OSC32_IN - -

D2 PC15-OSC32_OUT - -

C11 PD0 FMC_D2 -

A12 PD1 FMC_D3 -

B11 PD2 SDIO1_CMD -

D10 PD3

DCMI_D5

PMOD18-DF-CKOUT

A11 PD4 PMOD4-RTS USART2_RTS

C10 PD5 PMOD2-TX USART2_TX

B10 PD6 PMOD3-RX USART2_RX

A10 PD7 OSCPI1_IO7 -

L12 PD8 FMC_D13 -

N15 PD9 FMC_D14 -

L13 PD10 FMC_D15 -

L14 PD11 OSCPI1_IO0 -

L15 PD12 I2C4_SCL -

K11 PD13 I2C4_SDA -

K12 PD14 FMC_D0 -

K13 PD15 FMC_D1 -

B3 PE0 FMC_NBL0 -

C4 PE1 FMC_NBL1 -

UM2569

STM32H7B3I-DK I/O assignment

UM2569 - Rev 6

page 39/53
