STACK Dash-2 Kart Logger 4. Configuring the Dash-2 Kart Logger
Users Guide 15
4. Configuring the 4. Configuring the Dash-2Dash-2 Kart Logger Kart Logger
Configuration mode
You put the Dash-2 Kart Logger into configuration mode by pressing Switches 1 and 2 together. You then work through the
configurable parameters in a preset sequence. Press Switch 3 to display the next configurable parameter. The configurable
parameters are displayed in the following order:
Configurable Parameter Setting Required
SHIFT RPM RPM at which gear shift light is to come on
Wheel Circumference Set a value in the units of measurement indicated.
TEMPERATURE SENSOR
SELECT
Select Temperature Sensor from CHT, EGT or WATER
HIGH CHT (or WATER) Maximum cylinder head or water temperature alarm
HIGH EGT Maximum exhaust gas temperature alarm
LOW BATT Minimum battery voltage alarm
LAPTIME Laptime Popup Duration
Wheel sensor pulses per
revolution (W.S. PULSES/REV)
Set the value to the number of magnets you have fitted on
your wheel.
Engine Speed (Cylinders) Number of cylinders in engine (for RPM)
Logging RPM RPM at which the logging option is automatically started.
GATE RPM Minimum RPM for the gated peaks and warnings to operate.
BAR WIDTH Display width of the performance meter, Standard value is
0.45 seconds
ACCEL LIMIT Maximum acceleration expected
DECEL LIMIT Maximum deceleration(braking force) expected
