STACK Dash-2 Kart Logger 2. Getting Started
Users Guide 3
2. Getting Started2. Getting Started
This section guides you through the initial unpacking and setting up of the equipment for pre-installation checks and familiarisation with
its operation.
Unpacking
You should find the following components in the shipping box:
Description 8201 8202 8203 8204
Display in Composite Housing without G sensor 1
Display in Composite Housing with built-in G sensor 1 1 1
Wiring Harness (ST872 ) 1 1 1 1
RPM Sensor (ST696 ST697 H.T. Pick-up) 1 1 1 1
Wheel Speed Sensor with magnets (ST669) 1 1 1 1
PCNIU Interface 1 1 1 1
Infra-red Lap Time Beacon (ST544) 1 1 1 1
9.6V NiCd Battery Pack (111410) 1 1 1 1
Charger for 9.6V NiCd Battery Pack 1 1 1 1
Software installation disks 2 2 2 2
Data Analysis Software User Guide 1 1 1 1
Dash-2 User guide (this document) 1 1 1 1
Kart logger fastener kit 1 1 1 1
Steering position sensor 1
Pedal sensor kit 2
CHT sensor Option Option
Water temperature sensor Option Option
