Stack Dash-2 - Table of Contents

STACK Dash-2 Kart Logger Contents
User Guide iii
ContentsContents
Preface i
Congratulations i
Registration Form i
Purpose of this manual i
Edition Notice i
Related Products From Stack Limited ii
Who to Contact at STACK in Case of Difficulty ii
Contents iii
1. Introducing the Kart Logger 1
How to Use this Manual 1
2. Getting Started 3
Unpacking 3
Optional Dash-2 Kart Logger Items 4
Items not included with your Dash-2 4
The Display Module 5
Wiring Harness 5
Connecting the Components 6
3. Operating the Dash-2 Kart Logger 7
Switches 7
Warning lights 8
Changing the display layers 8
Peak Values (Tell Tales) 11
Lap times 13
Gear shift light 14
4. Configuring the Dash-2 Kart Logger 15
Configuration mode 15
Setting or resetting configuration values 16
Leaving configuration mode 17
5. Using the Dash-2 Charts 18
All channels 18
All channels full 18
Carburettor setting 19
Corner radius 19
Driver activity 20
Driver compare 20
EGT & CHT 21
EGT & Water temperature 21
G forces 22
Gear ratio 22
Lap times 23
Rolling lap time 23
Speed & RPM 24
Speed & time compare 24
Steering 25
