Error! Main Document Only.6. Installing the Dash-2 Kart Logger STACK Dash-2 Kart Logger
28 Users Guide
The cables from the engine speed sensor (ST697 HT pickup) and the CHT sensor (ST758) carry interference from the ignition system,
and must be kept away from all the other sensor wiring until the signal has passed through the interface board located approximately
30 cm(12 in) from the connector. The engine kill switch and wiring also carries the interference, and the same rules apply to it.
The best way to achieve this is to run the HT and CHT sensor cables together along one side of a chassis tube, and the cables from any
other sensors along the opposite side of the tube.
Wiring labels
See Section 2 if you need to check the labels used to identify the individual cables in the wiring harness
