Page 10
F
C
G
D
A
E
B
# Part Number Qty Description
A 110-3402 4 SCREW, #8-18, 3/4”, HI-LOW, PHT, PH, CS, BO
B 110-4180 4 SCREW, M8x1.25, 65mm, SHC, HK, AS, BEC, NP, GR 10.9
C 110-4197 8 SCREW, M8X1.25, 25mm, FLANGED, HEX, ZP, Cl 10.9
D 110-4229 12 SCREW, M5x0.8x30, PHM, PH, CS, BZ, DP
E 110-4329 6 SCREW, M5x0.8x20, PHM, PH, CS, BZ, DP
F 110-4364 8 NUT, M8x1.25, AS, NP, FLANGE, SERRATED
G 110-4396 4 SCREW, M8x1.25, 35mm, SHC, HK, AS, BEC, DP, GRD-12.9
To Next Page
