Page 11
1. Remove outer cardboard
container (not shown).
2. Pry off two wooden supports
from the bottom of the pallet then
remove.
CAUTION: Staples from the
pallet may be sharp
3. Remove all packaging material.
Set aside hardware card 711-4155
for use.
Fig. 5
4. Pry off wooden plank at rear of
machine securing machine to
pallet.
Fig. 6
5. Roll unit off pallet to final install
location.
Fig. 7
