Diagnostic mode is used to verify the functionality of all physical key switches on the product. It is also used to
test the functionality of the HR systems.
Not Blocked
E-STOP Test
ON
Brake On/Off test Key Press Monitor HR Monitor
This mode is used to verify the functionality of all physical key switches on the product. It is also used to test the functionality of the
HR systems. To test the contact heart rate system, simply grab the heart rate grips. In the HR Monitor window the current measured
heart rate will be displayed as well as the word CONTACT. This signifies the source of the heart rate signal. To test the telemetry
heart rate system, either a heart rate strap or heart rate simulator is required. The current telemetry heart rate will be displayed in
the HR Monitor window as well as the word TELEMETRY.
E-STOP will display “blocked” if sensor is activated.
Fig. 34
