Page 55
Part Number Qty Description
050-5657 1 KEYPAD, SPEED PLUS MINUS, GAUNTLET II
050-5662 1 KEYPAD, SECONDARY STOP, 10G
050-5711 4 LABEL, CAUTION, PINCH, CHAIN DRIVE
050-5894 1 LABEL, GEN. WARNING, COMMERCIAL STAIRCLIMBER, NARROW
110-1823 2 NUT, THIN, JAM,1/2-13 x 5/16 THICK, BZ, GR-5
110-3328 9 SCREW, M6X1, 16MM, FHM, HE
110-3373 8 Screw, M10x1.5, 85mm, SHC, HK, AS, NKL, Gr-10.9
110-3402 4 SCREW, #8-18, 3/4”, HI-LOW, PHT, PH, CS, BO
110-3404 2 SCREW, M4x0.7x10L,PHT,PH,CS,BO
110-3504 4 Screw, M10x1.5, 40mm, SHCS, HK, AS, NP, EC-B, Gr-12.9
110-3548 1 Nut, Jam, M8x1.25mm, CS, ZP
110-3608 2 Screw, M4x0.7, 25mm, FHM, HK, AS, NKL, Gr-10.9
110-3671 34 NUT, “U”, BARREL, TAPERED, M5x0.8mm
110-3672 10 NUT, M8x1.25, AS, NYLOC, BLK E-COAT, GR-10
110-3673 5 NUT, M6X1, CS, JAM, BLK E-COAT, GR-8
110-3682 4 SCREW, M6x1.0, 30mm, SHC, HK, CS, GR 8.8, BLK E-COAT
110-3733 4 SCREW, M3 X 0.5, 10mm, BHC, HK, AS, ZP
110-3766 1 SCREW, M5X0.8, 50mm, SHC, HK, AS, BEC, Gr 10.9
110-3773 2 SCREW, M5x0.8, 35mm, SHC, HK, CS, ZP
110-3924 2 SCREW,M6x1.0,10mm,HHC,HE,AS,GR12.9,NKL,FT
110-3970 3 SCREW,M6x1.0,35mm,HHC,HE,AS,ZC,GR12.9
110-3973 12 NUT,M10X1.5,AS,ZC,NYLON
110-3993 1 SCREW, M5x0.8, 50mm, SHC, HE, CS, BEC, Gr 8.8
110-4015 1 SCREW, M4X0.7, 16mm, SHC, HK, AS, ZP, CL 10.9
110-4090 56 SCREW, #8-18, 0.625in, HI-LO, PHT, PH, AS, ZP
110-4114 9 Washer, M6, Ø6.5xØ16x1mm, ECB
110-4115 4 NUT, M6X1.0, NYLOC, ECB
110-4139 4 SCREW,M6x1.0,20mm,SHC,HK,AS,GRD-12.9,DAC-ZP
110-4180 4 SCREW, M8x1.25, 65mm, SHC, HK, AS, BEC, NP, GR 10.9
110-4197 8 SCREW, M8X1.25, 25mm, FLANGED, HEX, ZP, Cl 10.9
110-4199 1 SCREW, SPRING ANCHOR, M8x1.25 STUD
110-4206 1 NUT, M12x1.75, FLANGE, AS, BZ, SERRATED, CLASS 10
110-4218 1 WASHER, M6, 7x32x1.5mm, CS, ZP
110-4226 4 SCREW, ST4.8x1.6x13, PHTF, PH, CS, BZ, SF, 8.8
110-4229 26 SCREW, M5x0.8x30, PHM, PH, CS, BZ, DP
110-4297 2 SCREW, M4x0.7, 6mm, BHC, HK, CS, BEC, Gr 8.8
110-4329 6 SCREW, M5x0.8x20, PHM, PH, CS, BZ, DP
110-4353 2 SCREW, 1/2x13, 2.5 IN, HHC, HE, AS, ZP, PT, GR 10.9
110-4360 2 SCREW, M6x1.0, 45mm, HHC, HE, AS, ZP, FT, GR 10.9
110-4362 8 SCREW, M8x1.25, 90mm, SHC, HK, AS, ZP, Gr 10.9
110-4364 14 NUT, M8x1.25, AS, NP, FLANGE, SERRATED
110-4377 2 NUT, 1/2-13, THIN, NYLON LOCK
110-4380 2 SCREW, M8x1.25, 60mm, HHC, HE, AS, BEC, FT, GR 10.9
110-4396 4 SCREW, M8x1.25, 35mm, SHC, HK, AS, BEC, DP, GRD-12.9
120-3030 4 WASHER, 1/2 X 1.0625 OD X .093
120-3246 4 WASHER, M6, ISO 7089
120-3361 4 WASHER M5
120-3386 4 WASHER, M5, 5.3x10x1mm, BLK E-COAT
120-3387 26 WASHER, M8, 8.6x16x1.6mm, BLK E-COAT
120-3401 4 NUT, M5, LOCK, NYLON, ZP, Cl 10
120-3418 16 WASHER, M10, FLAT, 10.5x20x2, CS, BCE
120-3448 4 WASHER, FLAT, M10, 10.5mm ID x 20mm OD, 2mm THK
120-3454 4 SPACER, 10.2MM ID, 36MM OD, MOTOR, 4-TR
120-3455 8 WASHER, RUBBER, 14.1MMX36MMX5MM
120-3536 4 SPACER, 6.5 ID X 9 OD X 15MM, CS, ECB
130-1694 2 WHEEL, 4.0” OD X 0.5” BORE
130-1699 1 BELT, POLY V, 390J8
130-1839 2 JFM-1012-09, Bearing, Flange, Igus
130-1973 1 ASSY, CHAIN, #40, 1/2”, DRIVE W/ MSTRLINK, 4G
140-3514 1 RETAINING RING, EXT, Ø16mm
140-3588 1 CLAMP, SCREW MOUNT, BCS POWER
140-3777 1 KEY, ROUNDED, 3/16” X 3/16” X 1”
140-3783 1 SPRING, EXTENSION, DBL. HOOK, SM
140-3827 1 KEY, 3/16 X 0.75, SINGLE ROUND
140-3832 1 GROMMET, RUBBER, 25mm BORE, CABLE MNGT.
170-0729 2 KIT, CONTACT PLATES, HEART RATE SENSE
Part Number Qty Description
220-0270 1 ADAPTER,CORD LINE, NEMA 5-15
220-0271 1 ADAPTER,CORD LINE, NEMA 6-15
220-0272 1 ADAPTER, CORD LINE, CEE 7/7
220-0327 1 CABLE, HEART RATE, NECK/CONSOLE, SM
220-0328 1 CABLE, +/- & STOP, NECK/CONSOLE, SM
240-6846 1 CONNECTOR, 8 PIN, INLINE
240-6901 2 TAB, QUICK DISCONNECT, .250 TIN, PAIR
410-0959 1 ASSY, RESISTOR, 47OHM, 750W
560-0069 1 ASSY., GEAR TOOTH SENSOR, W/6 PIN CONN.
701-0468 1 ASSY, SPROCKET GUARD, L, 4G
701-0470 1 ASSY, SPROKET GUARD, R, 4G
711-3596 6 PLATE, COMPRESSION, P. BLOCK PATTERN
711-3644 1 WHEEL, DISK, RPM, 10G
711-3770 2 PLATE, NUT, JACK SCREW BASE, MOTOR YAW/PITCH
711-3963 1 ASSY, SENSOR, RPM, NRG
711-4000 1 ASSY, AXLE, TOP, 4G
711-4001 1 ASSY, AXLE, REAR, 4G
711-4004 14 ASSEM, STEP SHAFT, W/ HARDWARE
711-4008 1 IDLER ASSEM., TRANS. CHAIN, 4G
711-4009 1 PLATE, WASHER, TRANSMISSION
711-4011 1 ASSEM., TENSIONER, BEARINGS INCL., SM
711-4012 1 ASSY, TRANSMISSION BASE, 4G
711-4023 2 BRACKET, PILLOW BLOCK, ADJUSTMENT, 4G
711-4025 1 RUNNER PLATE, RIGHT, BOTTOM
711-4026 1 RUNNER PLATE, RIGHT, TOP
711-4027 1 RUNNER PLATE, LEFT, BOTTOM
711-4028 1 RUNNER PLATE, LEFT, TOP
711-4029 8 SPACER, RUNNER, 4G
711-4030 1 ASSEM., GEN. MOTOR & BRAKE, 4G, SM
711-4046-XX 2 ASSEM., HANRAIL BASE, W/RING, 4G
711-4076 7 ASSY, STEP, 4G
711-4085 8 ASSY, PLASTIC, MOUNT BRKT. 1, W/ SCREWS,, 4G
711-4086 1 ASSEM., SENSOR & HARDWARE, 4G
711-4108 2 ASSEM., THUMB PAD BASE, GRIP MODULE
711-4109 1 ASSY, PULLEY W/ SET, 195mm, J10, 4G
711-4115 1 SPROCKET, 20T, #40, W/ SET SCREWS
711-4116 2 CHAIN, #40, 0.5” PITCH, OFF SET LINK, STEPS, 4G
711-4118 1 ASSY, HARNESS, CSAFE, 4G
711-4119 1 CABLE, MAIN INTERFACE, 4G, SM
711-4120 1 ASSY, CABLE, POWER, 4G
711-4121 1 ASSY, CABLE, VIDEO COAX, 4G, SM
711-4136-XX 1 ASSEM., NECK, W/WIRING & LABELS, 4G
711-4137 1 ASSEM., FULL HANDRAIL, R, 4G SM
711-4138 1 ASSEM., FULL HANDRAIL, L, 4G SM
711-4139 2 CABLE, HEART RATE, PLATE, 4G
711-4140 1 CABLE, +/-, KEYPAD, 4G
711-4141 1 CABLE, STOP BUTTON, KEYPAD, 4G
711-4145 1 ASSY, ELECT, FRONT, 4G
711-4148-XX 1 ASSEM., SHROUD, L LOWER SKIRT, W/REFLECTOR, 4G
711-4151-XX 1 ASSY, SHROUD, PLASTIC, LOWER, TRI, L, SM, 4G
711-4152-XX 1 ASSY, SHROUD, PLASTIC, LOWER, TRI, R, SM, 4G
711-4155 1 KIT, HARDWARE PACK, 4G SM
711-4157-XX 1 ASSEM., SHROUD, R LOWER SKIRT, W/REFLECTOR, 4G
711-4158-XXX 1 ELECTRONICS, LCB, 4G SM
712-4022 1 POWER SUPPLY, 90-260VAC/12VDC 5A MIN
723-0110 4 SCREW, SET, M6X5
731-0421 6 SCREW, M8 X 1.25, 30MM, SHC, HK, CS
731-0584 5 SCREW, #8-18, 3/8”, PHTF, PH, CS, BEC, HI-LOW
731-1958 3 SCREW, M5X0.8, 20mm, SHC, HK, AS, NKL, Gr-12.9
731-2346 4 WASHER,M10,FENDER,BZ
731-2969 1 WASHER,M16,NP
740-4552 4 PILLOW BLOCK, Ø25mm ID
740-7023 2 ASSY, FOOT, W/ OVER MOLD
740-7896 2 Screw, M4.2, 12mm, PHT, PH, SS
