6.2 K1700 & K2300 Assembly of removable parts
After the installation, the stove should be fitted with the removable covers.
- Top front cover
To install the top front cover, place it over the stove (Figure-8a) and then tighten the screws that secure it to the top panel of
the stove (Figure 8b).
15a 15b
Figure 15 – Assembly of the top front cover
- Bottom front cover
The bottom front cover can be assembled by removing the screws located on the bottom part of the stove. Then place the part in
the appropriate position (Figure 9-a) and replace and tighten the screws again (Figure 9-b)
16a 16b
Figure 16 – Assembly of the bottom front cover
- Side covers
To install the stove's side covers position the covers and insert them as illustrated, onto the existing supports.
Figure 17 – Assembly of side covers
