Stanley K1200 Installation And Operating Instructions

40
1 . K1700SP Side panel 17kW 1 . K2300SP Side panel 23kW
2 . CO0802000000000 Expansion vessel 6L 2 . CO0802000000001 Expansion vessel 10L
3 . CO0315000000050 Water pressure sensor 0-3 Bar 3 . CO0315000000050 Water pressure sensor 0-3 Bar
4 . CO0803010000000 3 bar safety valve 4 . CO0803010000000 3 bar safety valve
5 . IC0467000000000 Clear hose w ith accessories 5 . IC0467000000000 Clear hose with aceesories
6 . CO0806022604274 1/2" male brass bush 6 . CO0806022604274 1/2" male brass bush
7 . IC0420000260003 Door complete w ith glass 7 . IC0420000260003 Door complete w ith glass
8 . IS0102015260001 Ash Pan 8 . IS0102015260001 Ash Pan
9 . IS3525000260002 Burn pot 9 . IS3525000260002 Burn pot
10 . IC0120000260001 Trap door 10 . IC0120000260001 Trap door
11 . CO0713000000212 M10 Levelling bolts 11 . CO0713000000212 M10 Levelling bolts
12 . IS1510080000002 Tube Silicone 330 long 6mm ID 12 . IS1510080000002 Tubo Silicone 330 long 6mm ID
13 . CO0315000000030 Pressure Switch 13 . CO0315000000030 Pressure Switch
14 . CO0306000000030 Boiler thermostat 95º C 14 . CO0306000000030 Boiler thermostat 95º C
15 . CO0306000000020 Pellet Hopper Thermostat 110º C 15 . CO0306000000020 Pellet Hopper Thermostat 110º C
16 . CO0803200000001 Ball valve M/F 1/2x1/2 16 . CO0803200000001 Ball valve M/F 1/2x1/2
17 . CO0805013250001 Drain hose M/F 1/2"x1/2" 500mm 17 . CO0805013250001 Drain hose M/F 1/2"x1/2" 500mm
18 . CO0312000000050 Additional Circuit board boiler models. 18 . CO0312000000050 Additional Circuit board boiler models.
19 . CO0312000000060 Circuit board boiler models 19 . CO0312000000060 Circuit board boiler models
20 . IC0490000000003 Extractor Fan boiler models 20 . IC0490000000003 Extractor Fan boiler models
21 . CO0310000000150 Motor w orm screw 21 . CO0310000000150 Motor w orm screw
22 . IC0212000300000 Back Panel K1700 22 . IC0212010300006 Back Panel K2300
23 . IC0114000000000 T143 Bushing 23 . IC0114000000000 T143 Bushing
24 . CO0728000000000 Rubber motor stop 24 . CO0728000000000 Rubber motor stop
25 . IC0414000260001 Motor support bracket 25 . IC0414000260001 Motor support bracket
26 . CO010226T150A12 Worm screw support 26 . CO010226T150A12 Wormscrew support
27 . IC0415000000000 Worm screw 27 . IC0415000000000 Wormscrew
28 . CO0315000000040 Air mass sensor 28 . CO0315000000040 Air mass sensor
29 . CO0303000000050 Igniter Steel 29 . CO0303000000050 Igniter Steel
30 . IC0409000000002 Igniter tube 30 . IC0409000000002 Igniter tube
31 . ME1006100000000 Universal connection interface 31 . ME1006100000000 Universal connection interface
32 . CO0317000000030 On-Off Switch- Filter 32 . CO0317000000030 On-Off Sw itch- Filter
33 . CO0312000000030 User Interface-Display 33 . IS1610000000000 Hopper door seal
34 . IS1610000000000 Hopper door seal 34 . CO0312000000030 User Interface-Display
35 . IS0116020300000 Top grill 17Kw 35 . IS0116020300002 Top plate
36 . CO0718230000112 Turbulator handle - M10 36 . CO0718230000112 Turbulator handle - M10
37 . IC0426000260000 Turbulator 37 . IC0426000260000 Turbulator
38 . IS1510080000003 Silicone hose 38 . IS1510080000003 Silicone hose
39 . CO0813000000009 Manual bleed tap 39 . CO0813000000009 Manual bleed tap
40 . CO0801000000006 Circulation pump UPM3 15-70 130 15h 40 . CO0801000000006 Circulataion pump UPM3 15-70 130 15h
41 . CO0304000000040 Water temperature sensor 41 . CO0304000000040 Water temperature sensor
42 . IS0116050260000 Turbulator Fixing plate 42 . CO010226T150A12 Wormscrew support
43 . CO010226T150A12 Worm screw support 43 . IS0116050260000 Turbulator Fixing plate
44 . IC0420000000002 Door complete with glass 44 . IC0420000000002 Door complete w ith glass
45 . CO0312000000035 Encoder 45 . CO0312000000035 Encoder
IS2030040400017
Door glass
IS2030040400017
Door glass
CO1206020000001
Extraction fan gasket
CO1206020000001
Extractiion fan gasket
Parts list K1700 Parts list k2300
