Stanley MC521 Pro User Manual

MC521 PRO Control Box
16 Document # 204090 REV D • www.stanleyaccess.com • 1.800.7.ACCESS
Copyright 2017, Stanley Access Technologies, LLC. All rights reserved. Reproduction
in whole or in part without the express written permission of Stanley is prohibited.
03.23.2017
Table 4. Magic Force/Magic Swing Configuration Codes -- Motor 1
Index
Min.
Value
Max.
Value
Description
Defaults
Low Energy Full Energy
00 05 35 Open speed, revoluons per second 06 25
01 03 12 Check speed, revoluons per second 04 04
02 05 40 Stall speed, percent of PWM counts 15 15
03 00 99 Open check length 20 45
04 00 99 Magic Touch sensivity (00 = OFF, 01-99 = sensivity)
(01 = max. sensivity)
00 00
05 01 99 Magic Touch hold open me (25 sec. max. = 99%) 22 16
06 01 99 Hold-open delay in percent (25 sec. max. = 99%) 21 06
07 05 75 Open torque 25 75
08 05 75 Check torque 25 40
09 05 75 Stall torque 25 25
10 00 20 Open Check Boost 09 12
Continued Next Page
