Stanley MC521 Pro User Manual

MC521 PRO Control Box
03.23.2017
1.800.7.ACCESS • www.stanleyaccess.com • Document # 204090 REV D 51
Copyright 2017 Stanley Access Technologies, LLC. All rights reserved. Reproduction
in whole or in part without the express written permission of Stanley is prohibited.
Values shown as grayed out do not aect moon of the door and may need to be adjusted to suit the applicaon
Attachment 10
Table 5 Recommended Values for Dual Egress Swing Doors with Motor 1 as In-Swing
Index Description Heavy Weight Doors (350lbs)
Low Energy Full Energy
00 Open speed, revoluons per second 06 25
01 Check speed, revoluons per second 05 08
02 Stall speed, percent of PWM counts See Aachment 11
03 Open check 23 45
04 Magic Touch sensivity 00 00
05 Magic Touch hold open me HH=55
KP=22
HH=40
KP=16
06 Hold-open delay HH=55
KP=22
HH=15
KP=06
07 Open torque, percent of full torque 25 75
08 Check torque, percent of full torque 25 75
09 Stall torque, percent of full torque 25 25
10 Open Check Boost 12 14
11 Safety Logic 00 00
12 2S Operaon 00 00
13 Obstrucon Time HH=50
KP=20
HH=50
KP=20
14 Open Acceleraon Slope 60 60
15 Open Braking Slope 20 20
16 Delay of door moon. Motor 1 00 00
17 No Reverse on Obstrucon 00 NA
18 Lock Delay 00 00
19 Manual Mode sensor override 00 00
31 O Mode 00 00
32 Lock Logic 01 01
37 Unlock Time 10 10
HH = Hand Held
KP = Key Pad
