Stanley QB Expert User Manual

QB Expert Alpha Controller
190
Message Guide
Message Possible Cause Probable Solution
Major Consideration
That Led to Solution
To Clear/Reset from
Message Condition
Invalid PLC File
Bad command or
syntax used in the
PLC.json file
Read the entire file
and fix the syntax
issue
Invalid PLC File
appears on display
Press OK.
Delete the PLC file.
Read the entire file
and fix the syntax
issue.
Identifying Spindle
Trailing spindle is
wanting to connect
to lead controller
Choose a number
and add the spindle
Red, Greed,
Yellow Status
lights are blinking
in sequence on
trailing controller
and tool with ‘Add
Spindle’ dialog box
on display of lead
controller
Press OK.
Choose a number
and add the spindle
Operator pressed
the Identify button
under ANALYZE
Press OK
Display on lead
controller is on
ANALYZE screen
Press OK
Tool Disabled
An unprogrammed
Task has been
selected
Select a different
Task
Tool Disabled:
Undefined Task
message on display
when the operator
pressed the tool’s
start trigger
Program the
selected Task or
select another Task
that is already
programmed
A non-valid Job/
Task has been
selected
Select a different
Job/Task
Tool Disabled:
Invalid Job/Task
message on display
when the operator
pressed the tool’s
start trigger
Select a different
Job/Task from 1
to 99
Network needs to
know that a valid
unprocessed part
has entered the
station
Have a valid part
enter the station
Tool Disabled:
Network Protocol
message on display
when the operator
pressed the tool’s
start trigger
Have a valid part
enter the station.
Disconnect the
Ethernet cable from
the controller.
Accumulated bolt
count is equal to
Job/Task bolt count
Select a new Job/
Task.
Reset the Job.
Tool Disabled:
Error Proofing
message on display
when the operator
pressed the tool’s
start trigger
Select a new Job/
Task.
Reset the Job.
