Controller Operation
Instruction Manual
27
Tool Disabled
Along with the onscreen indication, the blue light on the controller and tool MFP
extinguishes and the STOPPED output asserts.
Tool Disabled Explanations:
Undefined Task – The selected Task is not programmed to run an audit step;
select another Task or program currently selected Task.
Invalid Job/Task – Appears when a Job or Task number less than one or greater
than 255 is selected.
Network Protocol – The plant control system issued a Stop via a network
protocol. Wait for the protocol to remove the Stop command.
Error Proofing – Error Proofing is turned on and either a Batch count has been
met, or the Job has not been reset. Reset with a Job Reset input.
Stop Issued – An Input is disabling the tool; remove the Stop input. May also be
caused by Job/ Task Verify inputs not matching selected Job/ Task.
System Initializing – The controller is booting up, please wait.
Cycle Lock-out – The Cycle Lockout timer is active, wait for it to reset.
Reject Count Exceeded – Indicates the Reject Count has been exceeded.
Internal PLC – The internal PLC is commanding the tool to STOP.
Not Armed – There are two things that can cause this event:
1. Tubenuts – By default tubenut tools require arming by tapping the MFB
before the trigger is pressed to run the tool.
2. Reset Reject – The fastening cycle is NOK and the MFB mode is set to Reset
Reject preventing the tool from running until the MFB is pressed to reset the
NOK.
