A Assembly
A.1
Bore dimension drawing for coolcept
3
devices
150 mm
240 mm
160 mm
300 mm
≥ 260 mm
≥ 160 mm
≥ 270 mm
742.643 | Z01
EN
750.661 | Z03 | 2016-09-12
73
