Heavy-Duty Telescopic Crane Owner’s Manual | Page 17
Main Cylinder
Valve Bank
Crane Horse Head
WARNING
28256
Overload Hazard
Bypassing the overload condition
by tampering with the overload
device can result in death or
serious injury.
Never tamper with overload
device.
25159
After stowing the crane, always return the valve
bank manual overrides to the neutral position.
Failure to return the manual overrides to the neutral
position can result in death or serious injury.
Movement Hazard
WARNING
Misuse Hazard
Two blocking the crane can result in death
or serious injury.
Never allow the hook block to contact the
boom tip by hoisting up, extending or
lowering the boom.
12300
Winch Pull
Boom Extending
Boom
Down
Decal Part Number: 12300
Decal Location: Crane Horse Head
Hazard Type: Misuse Hazard
Consequences: Can result in death or serious injury.
Avoidance: Never allow the hook block to contact
the boom tip by hoisting up, extending or lowering
the boom.
Decal Part Number: 25159
Decal Location: Valve Bank
Hazard Type: Movement Hazard
Consequences: Can result in death or serious injury.
Avoidance: After stowing the crane, always return
the valve bank manual overrides to the neutral
position.
Decal Part Number: 28256
Decal Location: Main Cylinder
Hazard Type: Overload Hazard
Consequences: Can result in death or serious injury.
Avoidance: Never tamper with the overload
device.
