Specifications 19
PN 44024
Chapter 4 - Specifications
Model EC3200 Crane
SPECIFICATION SHEET
Crane Rating: 11,500 ft-lbs (1.59 ton-meters)
Standar
d Boom Length: 7’ (2.13 m) from CL of Crane
Boom Extension: 1st stage: Hydraulic 48" (121.9 cm)
2nd stage: Manual 48" (121.9 cm)
Maximum Horizontal Reach: 15’ (4.57 m) from CL of Crane
Maximum Vertical Lift: 16’ 2” (4.93 m)
(from crane base)
Boom Elevation: -5 to +80 degrees
Stowed Height: 24” (61.0 cm)
(crane only)
Mounting Space Required: 18” x 15” (45.7 x 38.1 cm)
Approximate Shipping Weight: 730 lbs (331 kg)
Controls: Radio control standard for all functions.
Winch Specifications
Rope Length: 65 ft (19.8m)
Rope Diameter: 7/32" (.56 cm)
Line pull speed: 15 ft/min (4.6 m/min)
Max. single part line: 1600 lbs (725 kg)
Max. double part line: 3200 lbs (1450 kg)
Rotation: 410 degree power
(worm gear)
Lifting Capacities: 1625 lbs @ 7’ (737 kg @ 2.1 m)
640 lbs @ 20’ (290 kg @ 4.6 m)
Power Supply Required: 12 volt power unit
(2.0 gpm @ 2600 psi)
(7.57 lpm @ 179 bars)
*Subject to change without notification
