27
PN 44024
Installation 27
Chapter 6 - Installation
General Installation
This chapter is designed to serve as a
general guide for the installation of a Stellar
EC3200 Telescopic Crane on a Stellar
Service Body. Each installation is considered
unique so certain portions of this chapter
may or may not apply to your direct
application. If a question should arise during
the installation process, please contact
Stellar Customer Service at (800) 321 3741.
This crane is designed for use with a Stellar
Service Body installed on a vehicle that
meets the minimum chassis requirements of
the crane. Check with Stellar Industries
before installing this crane on a body other
than a Stellar Service Body.
WARNING!
The use of this crane on a
body not capable of
handling the loads
imposed on it may result
in serious injury or death.
Installation Notice
According to Federal Law (49 cfr part 571),
each final-stage manufacturer shall
complete the vehicle in such a manner that
it conforms to the standards in effect on the
date of manufacture of the incomplete
vehicle, the date of final completion, or a
date between those two dates. This
requirement shall, however, be superseded
by any conflicting provisions of a standard
that applies by its terms to vehicles
manufactured in two or more stages.
Therefore, the installer of Stellar cranes and
bodies is considered one of the
manufacturers of the vehicle. As such a
manufacturer, the installer is responsible for
compliance with all applicable federal and
state regulations. They are required to
certify that the vehicle is in compliance with
the Federal Motor Vehicle Safety Standards
and other regulations issued under the
National Traffic and Motor Vehicle Safety
Act.
Please reference the Code of Federal
Regulations, title 49 - Transportation, Volume
5 (400-999), for further information, or visit
http://www.gpoaccess.gov/nara/index.html
for the full text of Code of Federal
Regulations.
Notice:
PTO and Pump installation instructions are
provided by the corresponding
manufacturers. For more information on
which PTO and Pump fit your application,
please contact your local Stellar Distributor
or Stellar Customer Service.
Applicable Chassis: 16000 to 19000 GVWR
Cab to Axle: 84” (213.36 cm)
Body Length Nominal: 133” (337.82 cm)
Body Height: 44” (111.76 cm)
Body Width: 94” (238.76 cm)
Compartment Depth: 22” (55.88 cm)
Floor Width: 50” (127 cm)
Net Weight: 3220 lbs (1460.37 kg)
Optimal Service Body
for the EC3200 Crane:
T1-11 Service Body
Notice: Read this Page Before Installation of the Crane
The following pages will give a basic
overview of the installation process for the
Stellar EC3200. Please read through them
entirely and obtain a clear understanding of
the process before proceeding.
