Replacement Parts 43
Chapter 8 - Replacement Parts
Hydraulic Components
PART# DESCRIPTION
42840 HYDRAULIC SWING MOTOR
21151 GASKET - HYDRAULIC SWING MOTOR
42513 POWER UNIT 12V EC3200
44028 VALVE CARTRIDGE - POWER UNIT 12V #19012-D
44027 VALVE COIL - POWER UNIT 12V #11494-D
44029 MOTOR 12V - POWER UNIT #08111-1
44030 12V SOLENOID (12volt hydraulic system) #17757
44026 HYDRAULIC RESERVOIR - POWER UNIT 12V #14071
44025 FILL CAP - HYDRAULIC RESERVOIR
9803 C-BALANCE VALVE
43892 SEAL KIT - MAIN LIFT CYLINDER
43893 SEAL KIT - EXTENSION CYLINDER
3862 PRESSURE SWITCH
42821 CONTROLLER SOLENOID
C2027 O'RING - # 4 FACE SEAL
C2028 O'RING - # 6 FACE SEAL
D1245 O'RING - # 4 SAE
D1246 O'RING - # 6 SAE
Assembly Components
PART# DESCRIPTION
44375 WORM GEAR - ROTATION BEARING
44383 BEARING & SEAL KIT - ROTATION BEARING
44376 BEARING RETAINER - ROTATION BEARING
44377 ADAPTER HOUSING - HYDRAULIC MOTOR
20362 BUSHING 1.00" X 0.50"
0069 BUSHING 1.00" X 1.00"
42508 WEAR PAD 0.38" X 1.50" X 2.00"
42509 WEAR PAD 0.38" X 1.38" X 1.50"
42978 BOOM STOP FLAT
9320 PIN CAP 0.44" X 1.75" X 0.25" SS
C6353 WASHER 0.38 FLAT GR8
13573 CAP SCR. 0.38-16 X 1.00" GR8
0375 MACHINE WASHER -0.75" ID 14GA.
0423 MACHINE WASHER -0.75" ID 10GA.
42317 SHEAVE
42316 WIRE ROPE
42977 HITCH PIN 0.63" X 4.00"
9263 QUICK RELEASE PIN .38 X 3.00"
42505PC CRADLE PLATE
27710 SPRING ANTI-2-BLOCK
C6018 HOOK 3-TON
10709 SAFETY LATCH FOR 3 TON HOOK
C1592 GREASE ZERK
Electrical Components
PART# DESCRIPTION
35105 LIMIT SWITCH
11544 CORD REEL
17771 PUSH BUTTON (12volt hydraulic system)
41641 WINCH
28978 Bosch Relay
Radio Remote Components
PART# DESCRIPTION
42976 RADIO REMOTE SYSTEM
16975 E-STOP SWITCH
22600 TOGGLE SWITCH
20088 LOWER TRANSMITTER HOUSING
50932
HANDLE / TRIGGER ASSEMBLY
